مصباح ليزر ملون كامل الألوان مقاوم للماء في الهواء الطلق بقوة 25 واط RGB
- Balanced 25W Nichia RGB for Medium-Large Spaces: 7.5W red + 8.5W green + 9W blue deliver targeted brightness—9W blue cuts through semi-daylight (dusk festivals), while red/green ensure vivid brand projections or landmark details; avoids the “overpowered” waste of 30W+ models or “dim” limitation of 20W- models, perfectly matching 300-1000㎡ outdoor venues.
- Pangolin QuickShow Compatibility for Pro Animations: Integrates with industry-leading laser software to support 3D building mapping, real-time music sync, and pixel mapping—ideal for high-quality events like regional festival main stages or brand activation shows; gives creative teams full control over custom visuals (e.g., dynamic logos, storytelling animations).
Request a Quote
Send us your requirements for this product. Product information will be included automatically.
- المنتج
- مصباح ليزر ملون كامل الألوان مقاوم للماء في الهواء الطلق بقوة 25 واط RGB
- SKU
- CT-LL-25-WC3
الوصف
Technical Specifications
| رقم الموديل | CT-LL-25-WC3 |
|---|---|
| المعلمة | التفسير الموجه نحو القيمة والمشهد |
| Power Supply | Input Voltage: AC 100-240Vac, 50/60Hz (Global wide voltage, compatible with event generators, outdoor venue grids, and cross-region tours—no converters needed) |
| Light Source (Core: 25W Nichia Graded RGB) | Brand: Japan Nichia (imported, low light decay, high color stability; 12,000+ hours lifespan for frequent outdoor use); Power/Wavelength/Beam Specs: – Red (R): 7500mW@638nm (7.5W), Beam 5×6mm, Divergence <1.0mrad (warm saturation for brand logos/landmark details); – Green (G): 8500mW@525nm (8.5W), Beam 4×6.5mm, Divergence <1.0mrad (high visibility for dusk/night projections); – Blue (B): 9000mW@450nm (9W), Beam 3×6.5mm, Divergence <1.0mrad (daylight-resistant for semi-outdoor festivals); Total Power: 25W (covers 300-1000㎡ spaces—ideal for medium-large venues, no energy waste or dimness) |
| Beam & Projection Performance | Divergence: ＜1.0mrad (ultra-narrow beam—minimizes dispersion, ensuring sharp text/animations at 200-600m distance, e.g., mid-rise building projections or festival main stages); Modulation: 100k Analog/TTL (fast response for smooth color transitions—no “banding” in gradient effects like sunset simulations); Max Scanning Angle: 60° (wide coverage—1 unit covers a 60m-wide outdoor stage or 120m-long community square, reducing fixture count) |
| Control & Software | Control Modes: ILDA (professional programming), Sound Active (audio-synced for concerts), Auto (pre-set loops), DMX512 (stage console sync), Master-Slave (sync 2-3 units for 1000+㎡ coverage), SD Card (offline custom content); Control Software: US Pangolin (QuickShow—supports 3D mapping, real-time music sync, and custom animation editing for pro-level shows); Laser Show Content: Supports text, animation, beam effects, logos, and customized designs (flexible for brand activations or community events) |
| Durability & Transport | IP Rate: IP65 (fully waterproof, dust-tight—resists rain, snow, dust, and water jets for year-round outdoor use; no extra enclosures needed); Optical Path Sealing: Unique double-layer structure (fully sealed to prevent moisture/dust intrusion—protects Nichia diodes from outdoor elements like fog or light rain); Heat Dissipation: Air cooling (quiet operation—no audio interference with live music or venue announcements); Working Temperature: -20~40℃ (stable in extreme climates—winter light festivals or summer outdoor concerts); Dimensions & Weight: – Product: 56×42×23cm (sturdy for outdoor trussing/ground mounting); – Net Weight: 41kg (stable in windy conditions—resists gusts up to 12m/s); – Flightcase: 60×66×40cm, Gross Weight 57kg (foam-lined, shock-absorbing—tour-ready for regional event circuits) |
