Открытый водоустойчивый 10x60w одиночный луч точки управления красит фокус СИД бара двигая свет головы СИД задний свет

IP65 Heavy-Duty Outdoor Design: Waterproof & dustproof, resistant to rain, dust, and harsh outdoor environments – ideal for open-air concerts, architectural lighting, and outdoor festivals.
Multi-Light Source Pixel Control: 10×60W RGBW main LEDs (pixel-level control) + 3 groups of backlights (CW/WW/RGB) – creates layered, dynamic pixel beam effects and soft ambient lighting.
Wide 5°-46° Linear Zoom: Seamlessly switches between narrow, concentrated pixel beams (for long-throw highlights) and wide-area wash (for large-scale coloring) – adapts to diverse outdoor scenarios.
Professional Color Mixing: High-quality RGBW mixing + CW/WW warm-cool white adjustment – delivers uniform, vivid colors with no color break, suitable for stage atmosphere creation.

Technical Specifications

Параметр	Значение
Модель №.	CT-EM-1060Y-WLMPXA
Модель продукта	Waterproof Outdoor Zoom Pixel Beam Bar Moving Head Light (with LED Backlight)
Входное напряжение	100-240V~ 50/60Hz
Общая мощность	600W
LED Light Source (4 Types)	Main Beam: 10×60W RGBW LEDs (pixel control support); Backlight 1: 96×3W CW (Cool White) LEDs; Backlight 2: 96×3W WW (Warm White) LEDs; Backlight 3: 96×0.5W RGB LEDs
Spot Angle (Zoom Range)	5°-46° (linear zoom system)
Диммирование и стробоскоп	0%-100% smooth dimming; Multiple speed strobe effects
Movement Angle	Y-axis: 202°
Система управления	Channel Modes (optional): 17CH / 27CH / 99CH / 108CH / 168CH / 170CH; Control Protocols: DMX512, RDM; Software Upgrade: Via DMX connection
Display & Operation	LCD display screen (supports menu setting)
Соединения	Signal: 5-pin XLR socket (3-pin optional) (input/output); Power: Power socket + power connector (input/output)
Уровень защиты	IP65 (waterproof, dustproof – suitable for outdoor use)
Dimensions (L×W×H)	1010×125×370mm
Вес нетто	31kgs
