STORM Artnet 戶外防水 1400 瓦搖頭 LED 閃光燈
- 42 Independent Zones (14 RGB + 28 White) for Dynamic Effects: 784 RGB LEDs (14 zones) deliver pixel-level color chases/gradients, while 392 white LEDs (28 zones) provide focused wash—create custom visuals like:
– Stadium audience “wave” color transitions;
– Theme park parade route zone-specific lighting;
– Concert stage backdrop gradient fades;
97CH DMX unlocks full control, replacing 2-3 single-zone fixtures and reducing rigging load. - 220° Ultra-Wide Vertical Tilt + 16-Bit Precision: 220° tilt covers tall structures (20m stadium screens, skyscrapers) without repositioning; 16-bit precision (±0.1° accuracy) ensures 10+ units sync perfectly (e.g., projecting a unified brand logo); high-speed silent motor avoids audio interference with live music or stadium announcements.
- IP65 Full Waterproofing + Intelligent Cooling for All-Weather Use: IP65 resists rain, snow, and dust—safe for outdoor festivals, coastal landmarks, or winter light shows; high-conductivity radiator + fan speed auto-adjustment balances cooling and noise (quiet at 30℃, high-speed at 50℃+); overheating protection prevents shutdown during 12+ hour continuous use (all-night events).
- Intuitive LCD Touch Screen + Auto-Reset Function: Bilingual (Chinese/English) LCD touch screen works in dark backstages—users can quickly save presets (e.g., “festival mode,” “stadium mode”) or check temperature/faults; Y-axis auto-reset after misoperation reduces on-site troubleshooting time (critical for tight event schedules).
Request a Quote
Send us your requirements for this product. Product information will be included automatically.
- 產品
- STORM Artnet 戶外防水 1400 瓦搖頭 LED 閃光燈
- SKU
- CT-ES-1400-WM
描述
技術規格
| 型號 | CT-ES-1400-WM |
|---|---|
| 參數 | 價值與場景導向詮釋 |
| 電源供應及消耗 | Input Voltage: AC 100-240V 50/60Hz (Global wide voltage, compatible with stadium generators, international tour power systems, and permanent venue grids—no converters needed); Total Lamp Power: 1400W (allocated for 784 RGB + 392 white LEDs + motor/cooling system—stable for 12+ hours of continuous use, e.g., all-night theme park shows); Power Daisy-Chain: Input/output design, max 2 units @230V, 1 unit @120V (reduces cable clutter for large rigs, e.g., 10 units need only 5 power outlets @230V) |
| Dual-LED Core (RGB + White) | RGB LEDs: 784 pcs 0.5W ultra-bright (14-segment zone control) – Rich color mixing for dynamic effects (e.g., neon chases for festivals, pastels for weddings); 14 zones enable pixel-level customization; White LEDs: 392 pcs 3W ultra-bright (28-segment zone control) – High-brightness wash for key areas (stage performers, stadium scoreboards); 28 zones ensure focused coverage without dark spots; Lifespan: 50,000 hours (reduces replacement costs for permanent installations, e.g., theme park fixtures); Color Capability: Red/Green/Blue/White + infinite color changes (matches brand themes or seasonal decor) |
| Movement & Positioning | Vertical Tilt: 220° (16-bit precision scanning) – Wide coverage for tall structures (e.g., 20m stadium screens, skyscraper facades); Y-Axis Motor: High-speed silent 60 three-phase thickened motor – Smooth, quiet operation (no audio interference with live music); supports auto-reset after misoperation (reduces on-site fixes); Positioning: Optical electromagnetic encoding – High-precision positioning (±0.1° accuracy) for syncing multiple units (e.g., 20 units projecting a unified logo) |
| Control & Protocol (Pro-Grade) | Control Modes: 7 options – 8CH/11CH/13CH/24CH (simplified) /30CH/74CH/97CH (standard) – Adapts to complexity: – 8CH for basic on/off/tilt; – 97CH for zone-by-zone color/dimming/strobe control; Protocols: Standard DMX512, RDM (bidirectional communication for remote status monitoring), Artnet (network control for 100+ unit rigs); Signal Daisy-Chain: DMX512 input/output (3-core, max 30 units) – Scalable for large events (e.g., 30 units need only 1 DMX console); Display: LCD touch screen (Chinese/English bilingual) – Intuitive operation in dark backstages; shows sensor faults/temperature (proactive maintenance) |
| Performance & Durability | Strobe: Electronic (0.3-25 times/second) – Adjustable for energy levels (0.3Hz for subtle accents, 25Hz for concert peaks); Dimming: 0-100% linear electronic dimming (1.2K-25K adjustable frequency, gamma curve) – Flicker-free (suitable for video shooting, no frame distortion); Cooling: High-conductivity light aluminum radiator + fan intelligent monitoring – Auto-adjusts fan speed (quiet at low temps, high-speed cooling at 50℃+); built-in overheating protection (prevents shutdown); Protection Level: IP65 (fully waterproof/dust-tight – safe for rain/snow/dust, ideal for outdoor use) |
| Dimensions & Packaging | Product Size: 404×202×350mm (compact for 1400W power – fits standard trusses); Net Weight: 15KG, Gross Weight: 17KG (manageable for 2-person installation); Packaging: Waterproof shockproof flight box/carton (protects during tour transport or outdoor storage) |
