户外防水 50w RGB 全彩动画激光灯
- 50W Graded RGB for Super-Large Outdoor Spaces: 12W red + 18W green + 20W blue deliver industry-leading brightness—covers 1000-3000㎡ areas (e.g., 80,000-seat stadiums, city central squares) without dimness; 20W blue (daylight-resistant) ensures effects stand out even in direct sunlight, solving the “invisibility” problem of lower-power lasers in mega-events.
- IP65 Full Waterproofing for All-Weather Deployment: Certified to withstand rain, snow, dust, and water jets—no need for additional protective enclosures; ideal for permanent landmark installations (e.g., skyscraper亮化) or temporary international events (e.g., world expo shows); IP65 sealing protects internal components from outdoor elements, extending service life to 15,000+ hours.
- FB3/FB4/Pangolin Beyond for Creative Freedom: Integrates with the industry’s leading laser control ecosystem to support 3D building mapping, real-time music sync, and pixel-level customization—ideal for high-stakes events like stadium opening ceremonies or iconic landmark branding; gives creative teams full control to design unique, memorable visuals.
- 50K-B High-Speed Scanner + Ultra-Narrow Divergence: >35kpps @8° scanning speed ensures jitter-free animations at 500-1500m distances (e.g., projecting onto skyscrapers or stadium scoreboards); <1.0mrad divergence minimizes beam dispersion—no blurring or color distortion, even when covering entire city squares or audience sections.
Request a Quote
Send us your requirements for this product. Product information will be included automatically.
- 产品
- 户外防水 50w RGB 全彩动画激光灯
- SKU
- CT-LL-50-WC3
描述
技术规格
| 型号 | CT-LL-50-WC3 |
|---|---|
| 参数 | 以价值和场景为导向的诠释 |
| 电源 | Input Voltage: AC 100-240V, 50/60Hz (Global wide voltage, compatible with stadium generators, international tour power systems, and permanent landmark grids—no converters needed); Total Power: 1200W (allocated for 50W laser output + TEC/conduction cooling—stable for 12+ hours of continuous use, e.g., all-day festivals or multi-set concerts) |
| Laser Source (Core: 50W Graded RGB) | Laser Type: High-performance diode lasers (low light decay, 15,000+ hours lifespan for permanent installations); Power/Wavelength/Beam Specs: – Red (R): 12000mW@638nm (12W), Beam 5×6mm, Divergence <1.0mrad (warm saturation for brand logos/landmark details); – Green (G): 18000mW@525nm (18W), Beam 4×6.5mm, Divergence <1.0mrad (high visibility for daylight/long-distance projections); – Blue (B): 20000mW@450nm (20W), Beam 3×6.5mm, Divergence <1.0mrad (daylight-resistant for super-large outdoor spaces); Total Power: 50W (covers 1000-3000㎡ spaces—5x brighter than 10W models, no dimness in mega-venues) |
| Cooling & Heat Dissipation | Cooling Mode: TEC (Thermoelectric Cooling) + Conduction Cooling + Air Cooling (triple system keeps laser diodes at 25-30℃ during extended use—no overheating at 40℃ summer festivals); Heat Dissipation Component: Custom private mold radiator + temperature-controlled silent fan (maximizes heat transfer while minimizing noise); Fan: Silent temperature-controlled fan (adjusts speed based on heat—<40dB operation, no audio interference with stadium PA systems or live music) |
| Scanning & Modulation | Scanner: 50K-B high-speed scanner (>35kpps @8°) – Smooth, jitter-free animations for fast-moving effects (scrolling event slogans, 3D rotating logos) at 500-1500m distance; Linear Modulation: 100K analog linear modulation (richer color transitions—no “banding” in gradient effects like sunset-to-night simulations, critical for artistic projections); Suspension Angle: 360° (flexible mounting—project to ceilings, walls, or audience areas; adapts to complex venue layouts like stadium curves or skyscraper facades) |
| Control & Protection | Control Methods: Software (FB3/FB4/Pangolin Beyond), DMX control (stage console sync), Auto (pre-set loops), Voice Active (audio-synced); Protection: IP65 overall dust-proof/rain-proof (resists rain, snow, dust, and water jets—safe for outdoor deployment without enclosures); Key Advantage: FB3/FB4/Beyond compatibility enables pro-level programming for custom events, while simple modes fit non-technical users for daily operation |
| 尺寸和重量 | Product Size: 55.5×42×23.5cm (not including handle) – Compact for 50W outdoor use, fits standard industrial trusses; Weight: 35kg (stable in windy conditions—resists gusts up to 15m/s; manageable for 2-person installation, no heavy industrial equipment needed) |
